وحدة حفر الآبار Sany SR235

Type:Rotary Drilling Rig
Brand Name: SANY
Power Type:Diesel
Use: Construction
Voltage:24V
Drilling Diameter:1000mm
Drilling Depth: Max.70m
Place of Origin:Hunan, China
Weight:35000 KG
Dimension(L*W*H): 11,090 * 3,060 * 3,600 mm
RPM Range:20-50 RPM
Max. output torque: 250 kN.m
Maximum Hoisting Capacity:20 Ton
Maximum Feed Force:230 kN
Max.pull-down piston push:250 kN
Max.pulling force:300 kN
Main winch wire rope dia.:16 mm
Max.main winch line speed:80 m/min
Warranty: 1 Year

Features:
1.High Efficiency：Large core parameters such as high torque and crowd force; fast line speed of main rope to ensure high drilling efficiency in hard soil layer; it is suitable for overpass, high-speed rail, large buildings and other large hole foundation fields.

2.Full Stroke Crowd：Adopt a winch crowd system with long stroke, fast crowding, and rotary drive display function, suitable for all casing construction in the beach, pebble and backfill formation.

3.Economy and Energy Saving：Power optimization control technology is adopted to distribute power in real-time with the smooth and fast response of composite action; moreover, it has high fuel efficiency and low comprehensive fuel consumption.

4.Step Drum：Adopt step drum structure with a single layer to realize no crushing, no wear, and increase the service life of wire rope by 35%.

5.Intelligent Upgrade：HD touch screen, 3ms refresh frequency, smooth animation display.

6.Convenience：The rotary drive key bar is exposed for easy service and replacement; the main winching wire rope is fixed by a wedge, which is easy to disassemble and assemble. Some lubrication points are exposed for easy service.

***Packaging & Shipping:

*We can pack and ship the equipment according to your specific needs. Here are the most common options:

*Container: This is the cheapest and fastest method. It requires disassembling the machine to fit it inside.

*Flat Rack: Ideal for heavy equipment. For example, one flat rack can ship a two-wheel loader or two 20-ton excavators (with a maximum load of 36 tons).

*Bulk Cargo Ship: The best solution for large construction equipment, as it typically requires no disassembly.

*Ro-Ro Ship: With this method, the machine is simply driven directly onto the ship, so no disassembly is needed.

***Frequently Asked Questions:

*What is the Minimum Order Quantity (MOQ) and payment terms?

*The MOQ is just 1 set. We accept payment by T/T (Telegraphic Transfer), and other terms are negotiable.



Call to Action
This meticulously maintained crane represents an outstanding opportunity for serious buyers. Contact us today for detailed specifications, high-resolution photos, and our competitive pricing. Ready for immediate inspection and purchase!

Why Choose This Crane?
✓ Low operating hours ensure extended service life
✓ Comprehensive safety features protect your investment
✓ Premium comfort features boost operator productivity
✓ Immediate availability eliminates project delays
✓ Priced below market for quick sale

Contact Information
[Haode Machinery]
whatsapp [إظهار قائمة الأسماء]
email [إظهار قائمة الأسماء]
web site [إظهار قائمة الأسماء

Note: All maintenance records available for review. Financing options possible for qualified buyers.
